Oxima® 2
Oxima® 2 offering highly efficient Tabletop Pulse Oximeter .
Incorporating advanced technology, Tabletop Pulse Oximeter offers excellent performance. Further, our Tabletop Pulse Oximeter is highly acclaimed for its arouses

Oxima® 2 can be applied in the hospital's operation room ICU clinic section office
Out-patient department sickroom and emergency treatment.
Oxima® 2 offering highly efficient Tabletop Pulse Oximeter .
Incorporating advanced technology, Tabletop Pulse Oximeter offers excellent performance. Further, our Tabletop Pulse Oximeter is highly acclaimed for its arouses

Oxima® 2 can be applied in the hospital's operation room ICU clinic section office
Out-patient department sickroom and emergency treatment.
Read More
2.8 inch color screen and large red digits LED
Replaceable probe (adult, paediatric, neonatal)
Battery capacity display and low battery warning message
Large screen: SpO2, PR are displayed on LED screen,
Plethysis waveform display for 24 hours or AC and removable,
rechargeable
Li-ion battery, up to 4 hours operating time
Storage/viewing of trend data in up to 3888 group,
time interval of data storage adjustable
Audible and visual alarm when parameters are exceeded and sensor is turned off
USB port for connection to a computer, unique remote monitoring
software that transmits data synchronously over the Internet

Options:
Bluetooth Function built in
Bluetooth Printer

Oxima2 vital signs monitor four parameters: NIBP SpO2 TEMP and pulse rate

NIBP:
Measurement method: Oscillometric
Range: Adult: 30mmHg~255mmHg Pediatric: 30mmHg~160mmHg
Unit of measurement: MmHg/kPa selectable
Measurement mode: Manual Auto STAT
Type of measurement: SYS DIA MAP
Measuring interval in AUTO mode : 1 2 3 5 10 15 20 30 45 60min
Measuring time in mode STAT: 5 min
Resolution: 1mmHg
Overpressure protection: Adult: 300mmHg Pediatric: 220mmHg

SpO2 :
Range: 0 -100%
Resolution: 1%
Accuracy: 2% (90~99%) 3% (70~89%) not specified (< 70%)

PR :
Range: 30bpm~250bpm
Resolution: 1bpm
Accuracy: 2bpm
Temperature:
Channel: 1
Input: Heat sensitive body surface resistance temperature sensor
Unit of measurement: C/° F selectable
Range: 0~50
Resolution: 0.1
Accuracy: 0.1
Environment:

Temperature
Operation: 0C~45
Transportation and storage: -20C~60C
Humidity
Operation: 15%~95% (non-condensing)
Transport and storage: 10%~95% (non-condensing)
Altitude
Operation: 86kPa ~ 106kPa
Transportation and storage: 50kPa~106kPa

Power requirements:
AC power adapter
Input: AC 100~240V 50/60Hz 0.7A
Output: 5V 2.5A
Internal battery
Type: 2.8A built-in Li-ion rechargeable battery
Operating time: 5 hours stand-by time when battery is full.
Recharge time: 8 hours

Dimensions: 280mm × 190mm × 100mm
Net weight: 1000g

Standard:

SpO2 Cable (Adult)  ........ 1Pcs
NIBP Cuff (Adult)  ............ 1Pcs
NIBP Tube(150cm)  ......... 1Pcs
Tempreture probe ........... 1Pcs
USB Cable    . ................... 1Pcs
Power Adapter .............. 1Pcs
Cleaning Cloth ........... ..... 1Pcs

Options:

NIBP Cuff (infant 8 - 14 cm 5/Bag)
Paper Role
Bluetooth printer

Product Features

    2.8 inch color screen and large red digits LED
    Replaceable probe (adult, paediatric, neonatal)
    Battery capacity display and low battery warning message
    Large screen: SpO2, PR are displayed on LED screen,
    Plethysis waveform display for 24 hours or AC and removable,
    rechargeable
    Li-ion battery, up to 4 hours operating time
    Storage/viewing of trend data in up to 3888 group,
    time interval of data storage adjustable
    Audible and visual alarm when parameters are exceeded and sensor is turned off
    USB port for connection to a computer, unique remote monitoring
    software that transmits data synchronously over the Internet

    Options:
    Bluetooth Function built in
    Bluetooth Printer


Product Specifications

    Oxima2 vital signs monitor four parameters: NIBP SpO2 TEMP and pulse rate

NIBP:
Measurement method: Oscillometric
Range: Adult: 30mmHg~255mmHg Pediatric: 30mmHg~160mmHg
Unit of measurement: MmHg/kPa selectable
Measurement mode: Manual Auto STAT
Type of measurement: SYS DIA MAP
Measuring interval in AUTO mode : 1 2 3 5 10 15 20 30 45 60min
Measuring time in mode STAT: 5 min
Resolution: 1mmHg
Overpressure protection: Adult: 300mmHg Pediatric: 220mmHg

SpO2 :
Range: 0 -100%
Resolution: 1%
Accuracy: 2% (90~99%) 3% (70~89%) not specified (< 70%)

PR :
Range: 30bpm~250bpm
Resolution: 1bpm
Accuracy: 2bpm
Temperature:
Channel: 1
Input: Heat sensitive body surface resistance temperature sensor
Unit of measurement: C/° F selectable
Range: 0~50
Resolution: 0.1
Accuracy: 0.1
Environment:

Temperature
Operation: 0C~45
Transportation and storage: -20C~60C
Humidity
Operation: 15%~95% (non-condensing)
Transport and storage: 10%~95% (non-condensing)
Altitude
Operation: 86kPa ~ 106kPa
Transportation and storage: 50kPa~106kPa

Power requirements:
AC power adapter
Input: AC 100~240V 50/60Hz 0.7A
Output: 5V 2.5A
Internal battery
Type: 2.8A built-in Li-ion rechargeable battery
Operating time: 5 hours stand-by time when battery is full.
Recharge time: 8 hours

Dimensions: 280mm × 190mm × 100mm
Net weight: 1000g
